Car Battery Ground Cable Size

Most of the cost is the ends and labor.

Car battery ground cable size.

This diagram illustrates proper vehicle grounding both to the engine block and also directly back to the battery as your vehicle s steel frame has only 20 of the conductivity as. A short ground cable of the same size can be run to the frame but another short cable of the same size should run from the engine to the frame to complete the ground circuit. Copper conductor ampacity based on 75 c 167 f reference. A matching size ground cable needs to be connected between the engine trans combination and the frame for vehicles with short ground cables from the battery to the frame and those with a ground cable running all the way to the starter.

For very long cables for example 15 foot long battery cables to relocate your battery go one size larger. Cable size ampacity chart. The manufacturers make stock battery cables as small as possible but still get the job done. Heavy 2 gauge cable should be used to connect the battery negative terminal to the engine block or starter mounting bolt.

As far as i know these values are valid as of today. In terms of actual wiring you want to use at least 14 gauge wire for the body ground see our ground kit for more info. The photos and captions chronicle the installation of an optima battery in a bitchin finned aluminum battery box within the trunk of my deuce hi boy roadster. A braided copper ground strap is best attaching the engine to the frame.

Battery wire size per voltage amperage load and length chart below shows minimum cable size to use awg wire. In summary when selecting the correct size of battery cable you need to take into account the total maximum amperage your electrical system requires the voltage of your system usually 12 volts the total length that your cables need to be and the amount of voltage drop you are willing to accept versus the amount you want to spend. I recommend building cables larger than stock. Choosing the correct gauge automotive wire depends on the acceptable voltage drop length of the feeder branch circuit conductor load amperage and the ambient temperature of the compartment where the primary wire will pass through.

Choose a higher ambient temperature when conductors are expected to pass through. The following maximum amps versus cable size awg come from the nec version 2011. Going up a size or 2 is worth it in the long run. Outside engine compartments the ambient temperature should generally be 20 c.

Wiring sizes measure from smallest to largest on a numerical scale with zero for the largest size of wire and larger numbers as the wire size decreases.
